SYNAPTICON SOMANET Node 400 - Safety PLC PM (Plus-Minus Output) + Drives

1.5.6.3.2 Safety PLC PM (Plus-Minus output) + drives
Allows safety functions up to SIL 3, PL e, cat.3.
Note
Note
Safety GND functions as a secondary line when a PLC with Plus-Minus output is used.
Safety GND functions as a secondary line when a PLC with Plus-Minus output is used.
Attention
Attention
In case of multiple drive connection, ensure that the output driver has sufficient current driving
In case of multiple drive connection, ensure that the output driver has sufficient current driving
capability.
capability.
