2.1.10 External hard drive plug
Use to connect an external eSATA hard drive be utilised for local video recording
2
2.1.11 Audio output
To connect an external speaker
2.1.12 USB ports
Use to connect USB devices (e.g. memory stick) to update firmware or for exporting recordings (to be
implemented in future version)
2.1.13 Ethernet Ports
The unit has two 1000BaseT Ethernet ports to be used to connect to your Network LAN / WAN.
2.1.14 SFP network port
Can be used to connect a SFP fibre module.
2.1.15 Reset button
To press the recessed Reset button you need to use a suitable fine pointed tool.
Pressing the Reset buttons will reset the unit.
2.1.16 SD memory card slot
Use to insert an SD memory card to be utilised for local video recording
3
.
2.1.17 LED
The LED will light up dim blue when the unit is powered up and will become brighter once the unit is
operational.
2
To be implemented in a future version
3
To be implemented in a future version
