e1600 User Manual, Issue 1 © Synectic Systems Group Ltd 2012. All Rights Reserved
Specifications subject to change. E&OE Page 66
Appendix A – Technical Specifications
Video Inputs: 16 channels
Analogue: Composite PAL / NTSC
Termination: 75 Ohm
Resolution: D1/CIF
Rate: 25 frames (50 fields) PAL; 30 frames (60 fields) NTSC
Compression: H.264 AVC high profile (MPEG4 part 10) H.264 SVC
Data Rate: Max 6Mbps per stream Max 90Mbps per 16 channels
GOP Structure: I & P (with configurable length)
Input to Ethernet Latency:<100ms
Input: 16 mono channels
Compression: G711
Line Out: 2V RMS, 3.5mm jack
PSU Input: 100 - 240VAC auto ranging
Consumption: <100W
Interface: Dual 10/100/1000BASE T Single Open Module Slot per16 channels
Protocols Supported: RTP/RTSP, TCP/IP, UDP, IGMP, SNMP, HTTP
Built in Layer 2 Switch Supporting: VLAN Tagging, QoS, ACL, Spanning Tree
In: 16 alarm inputs, contact closure
Out: 4 outputs
COM ports: 1* RS485 /RS422 software selectable on terminal blocks 1 * RS232 on DB9
Size: 1RU (H) x 440mm (W) x 243mm (D) (including rear connectors) 19” rack mountable
Weight: 4Kg (unpacked)
Operating Temperature: 0°C to +55°C ambient (32°F to 131°F)
Storage Temperature: -40°C to +100°C (-4°F to 212°F)
Humidity: 80% atmospheric non-condensing
Onboard Storage: Optional utilizing front mount; SD card slot and eSATA support
Appendix B – Part Codes
SY1490 ENCODER E1600 16 CHANNEL H264
