T Scale L10 Series User Manual

T-Touch T-Touch POS Scale
74
6.2 Specification
Capacity
6 ~ 30kg
External Resolution
2 x 3000e
Tare range
Max-1d
AD Type
Sigma delta
AD Speed
Max. 60 times/second
Weighing Unit
kg, g, lb,
Calibration Unit
kg, g, lb
Load Cell Excitation
5VDC
Operation Temperature
0~40ºC
Operation Humidity
<95%
Display
10” / 8”/7” TFT LCD
Display resolution
800x480 (8/7”), 1280x800 (10” Display)
Display H/V ratio
16:9
Touch Control Mode
Resistance Touch Screen
Pan Size
L10/PL10: 388*277 (mm)
L8: 370*240 (mm)
Communication Interface
2xRS-232, 1x RJ11,1x RJ-45, 2xUSB
Optional interface
Wifi
Operating System
TOS II
CPU
CORTEX A9
RAM
1GB
Data memory
1GB
Power
110V~220V AC Adapter
12V/5.0A (L10), 12V/2500mA (L8
Battery
L8: 6V/10Ah
L10: N.A
