Diagnostics
6–12 TA I
NSTRUMENTS
DSC A
UTOSAMPLER
CE
Table 6.3
Explanation of Sensors
Sensor Indication
Lid #3 storage 1 = Lid #3 (the large lid)
is in its storage
position.
0 = Lid #3 is not in its
storage position.
Lid #2 storage 1 = Lid #2 (the medium-
sized lid) is in its
storage position.
0 = Lid #2 is not in its
storage position.
Lid #1 storage 1 = Lid #1 (the small lid)
is in its storage
position.
0 = Lid #1 is not in its
storage position.
Tray 1 = The sample tray is
fully inserted.
0 = The tray is not fully
inserted.
R-axis 1 = The turret arm is
centered over the
turret assembly
(halfway between the
innermost and outer-
most limits; see Figure
6.3).
0 = The arm is not
centered over the
turret assembly.
(table continued)
