1–23TA I NSTRUMENTS DSC A UTOSAMPLER CE
When the Autosampler CE is in automatic
mode, you can use the controller keyboard to:
 Input experimental parameters
 Create, edit, and execute Autosampler CE
run sequences that automatically load
samples, run methods, and unload samples at
the end of the experiment
 Maintain a log that records all activities of
the Autosampler CE.
Axis Terms
The terms r-axis, q-axis, and z-axis are used to
describe the three axes of motion of the Au-
tosampler CE.
Inward and outward movement of the turret arm
occurs along the r-axis:
Figure 1.12
The R-Axis
Terminology
