Introducing the DSC Autosampler CE
TA I NSTRUMENTS DSC A UTOSAMPLER CE1–24
Rotational movement (clockwise and counter-
clockwise) occurs along the q-axis (theta-axis):
Figure 1.13
The q-Axis
Upward and downward movement occurs along
the z-axis:
Figure 1.14
The Z-Axis
