TA I
NSTRUMENTS
DSC A
UTOSAMPLER
CE 4–21
Calibrating the
Lid Storage Positions
To calibrate the lid storage positions, follow these
steps:
1. Access the Autosampler CE keypad by
loosening the captive thumbscrews on the
keypad cover and tilting the cover down.
2. Press RESET SAMPLER and ENTER to
bring the Autosampler CE to home position.
3. Check that the three cell lids are in their
storage positions (see Table 4.1).
4. Use the motion keys to position the grippers
over lid #1 (small lid). Press the GRIP and
RELEASE keys repeatedly to ensure that the
fingers can firmly grasp the lid, and watch
carefully to ensure that each finger contacts
the lid at the same time (see Figure 4.3 on
the next page).
Performing the Calibration
