TAC 2413 Handbook Commissioning protocol/List of parameters
App:2 (6), 0-004-7614-0 (GB) TAC AB, 1998-10-23
P No. Parameter Min. Max. Step Default Change Comment
P 00 Time. Indication and Off, Manual, Timed operation
choice of operating mode 1/2 and 1/1 speed
P 01 Supply air temperature 0,1 °C Measured value
P 02 Supply air temperature setpt 0,1 °C Calculated value
P 03 Room temperature 0,1 °C Measured value
P 04 Room temperature setpoint 0,1 °C Calculated value
P 05 Return air temperature 0,1 °C Measured value
P 06 Return temp. heating coil 0,1 °C Measured value
P 07 HEX efficiency (%) 1 % Measured value
P 08 Exhaust air temperature 0,1 °C Measured value
P 09 Outdoor temperature 0,1 °C Measured value
P 10 Heating setpoint 0 °C 50 °C 0,1 °C 20 °C
P 11 Cooling setpoing 0 °C 50 °C 0,1 °C 22 °C
P 12 Weekly program 1/2 speed 1/2 hr 07–17 Monday to Friday (single speed op.)
P 13 Weekly program 1/1 speed 1/2 hr –
P 14 Timer, extended operation 0 min 300 min 1 min 120 min
P 15 Yearly program 1 6 1 1 Choice of holiday period 1–6 (below)
123 4 56
Start (P 16):
Stop (P 17):
P 16 Holiday start date 01 00 12 31 0100 Start date for holiday period in P 15
P 17 Holiday end date 01 00 12 31 0100 End date for holiday period in P 15
P 18 Output signal to HEX (%) 0 100 1 % N.B.! Check the actuator’s direction
P 19 Outp. signal, heat. valve (%) 0 100 1 % N.B.! Check the actuator’s direction
P 20 Outp. signal, cool. valve (%) 0 100 1 % N.B.! Check the actuator’s direction
P 21 Winter/Summer period (stat.) 0=Winter, 1=Summer
P 22 Night cooling (status) (0/1)
P 23 Defrosting (status) (0/1)
P 24 Night cooling setpoint 0 °C 50 °C 0,1 °C 19 °C
P 25 Night heating setpoint 0 °C 50 °C 0,1 °C 16 °C
P 26 Supply air heat., min. setpt. 0 °C 50 °C 0,1 °C 14 °C
P 27 Supply air cool., min. setpt. 0 °C 50 °C 0,1 °C 12 °C
P 28 Supply air, max. setpoint 0 °C 50 °C 0,1 °C 35 °C
P 29 Frost protection setpoint 4 °C 50 °C 0,1 °C 8 °C
P 30 Damper control, mode choice 0 0 = Economy, 1 = Comfort
