CHAPTER 7 MANUAL OPERATION
70
5. FRAME ORIGIN MEMORY (TEHX-C, TFHX, TFHX-C)
<How to call the screen>
1. Select frame origin memory
The machine will perform frame travel auto-
matically, and memorize the origin of the
embroidery frame.
Perform this operation after the software was
installed or when the frame was moved dur-
ing turning off the power.
2. Execute
Execution of frame origin memory will
cause the frame to move automatically to
search the origin.
When the machine memorizes the origin, the
frame will return to the original position.
WARNING
When performing this operation, do not put your hands under the
needle or on the machine table. If your hands are under the needle
or on the machine table, you may be injured by the needle or the
moving frame.
(GC03)
Xa:43.2
Ya:-276.1
!
Screen 1400
1
Xa:43.2
Ya:-276.1
Screen 1400
OK?
2
Xa:43.2
Ya:-276.1
To Next Page
