1-15
In this Notebook PC, the CPU compartment and Memory
compartment locate under the keyboard panel. If the
CPU and Memory compartments of this Notebook PC
need to be fixed or upgraded, they should be reached by
lifting the keyboard panel.
We Reminds Yo
…
Battery Release Button
It is a bounce-back device as a preparation for releasing the
battery pack. Press it with one hand and pull the battery pack
carefully with the other.
Ventilator
The ventilator is designed to cool the system. DO NOT block
the ventilator for air circulation.
Battery Pack
Supply power to your computer when the AC adapter is not
connected. (See Introduction to the Power Source in Chapter 4
for more information)
Screw Box for releasing Optical Device
Use screwdriver to remove Optical Device from Notebook PC.
To Next Page
