Tascam DP-01 User Manual

EQ settings
28 TASCAM DP-01 Owner’s Manual
Advanced techniques
EQ settings
This can help you
emphasize the
particular points of the record-
ings on each track.
On the DP-01, you can set the frequency at which the EQ HIGH and EQ LOW
controls work; individually for each channel.
1 Press MENU, and then select the PREFERENCE menu.
The NSP setting is
only available on
the DP-01FX. The DP-01 will not
show this option.
2 Use the arrow keys to scroll to EQ FRQ:
3 Press the y cursor key:
4 Use the cursor keys and wheel to set these parameters.
Source This is the track affected by this setting, from Track1 through Track8.
High This is the frequency for the EQ HIGH control. Choose from 1.7, 1.8,
1.9, 2.0, 2.2, 2.4, 2.6, 2.8, 3.0, 3.2, 3.4, 3.6, 3.8, 4.0, 4.5, 5.0, 5.5,
6.0, 6.5, 7.0, 7.5, 8.0, 9.0, 10, 11, 12, 13, 14, 15, 16, 17, 18 (all mea-
sured in kHz).
Low This is the frequency for the EQ LOW control Choose from 32, 40, 50,
60, 70, 80, 90, 100, 125, 150, 175, 200, 225, 250, 300, 350, 400,
450, 500, 600, 700, 800, 850, 900, 960 (Hz), 1.1, 1.2, 1.3, 1.4, 1.5, or
1.6 (kHz).
-- PREFERENCE --
Post : 1.5Sec
EQ FRQ.
NSP : 10 l
--EQ FREQUENCY -
Source / Track1
High : 10kHz
Low : 100 Hz

Tascam DP-01 Specifications

General

Tracks	8
Simultaneous Recording Tracks	2
Phantom Power	Yes
Display	LCD
Sampling Frequency	44.1 kHz
A/D Resolution	24-bit
D/A Resolution	24-bit
Power Supply	AC adapter
Inputs	2 x XLR/TRS combo
Outputs	Stereo RCA
EQ	2-band per channel
Effects	Reverb
