Multi-effect
60 TASCAM DP-01 Owner’s Manual
DP-01FX Appendix
Multi-effect
The DP-01FX contains an input effector, which contains different types of effect,
grouped by the type of input (electric guitar, acoustic guitar, vocals, etc.) that
they are suitable for.
Assigning the effect
Although there are two inputs, the multi-effect can only drive one of them at a
time.
The multi-effect produces a stereo output, so you can assign the output to two
tracks (see “Assigning inputs” on page 20).
… Press and hold the SHIFT key and press the MULTI key so that either the
A or B indicator lights, showing the input which will use the multi-
effect.
There is a third setting in which neither indicator is lit, showing that
the multi-effect is not in use on either effect.
Selecting the effect type
… Press the MULTI key alone to bring up the multi-effect selection and
editing screen:
… Press and hold the SHIFT key and turn the TYPE control to scroll
through the different effect types available:
The effect (third line of the display) also changes as you change the
type, and so does the parameter value.
Selecting the effect
… Turn the TYPE control to scroll through all available effects (including
those in other effect types. Effects available are given in (“Available
multi-effect settings” on page 61.
Setting the parameter
… Each multi-effect has one parameter (shown as PAR).
… Use the PARAMETER control to set the value of the parameter (the
parameter which is changed and the range of values differ according to
the selected effect).
Figure 3.1: Effect controls
- MULTI EFFECT -
< TraDist >
.. EGTR ..
PAR: 83 VOL:100
EGTR Electric guitar
AGTR Acoustic guitar
BASS Bass guitar
VOCAL Vocals
DRUM Drums and percussion
