Advanced techniques
TASCAM DP-01 Owner’s Manual 55
Specifications
Specifications
Analog specifications
Digital specifications
Audio performance
INPUTs (A and B)
1/4" phone (unbalanced) XLR balanced (DP-01FX only)
Input impedance > 10kΩ (max), or 1 MΩ (A only) with switch in
GUITAR position
2.4 kΩ
Nominal input level –10 dBV –8 dBu
Maximum input level +6 dBV +8 dBu
EFFECT RETURN
2 x 1/4" phone (unbalanced)
Input impedance 10 kΩ
Nominal input level –10 dBV
Maximum input level +6 dBV
STEREO MIX
2 x 1/4" phone (unbalanced)
Input impedance 10 kΩ
Nominal input level –10 dBV
Maximum input level +6 dBV
LINE OUTPUT
2 x unbalanced RCA (pin) jacks
Output impedance 1 kΩ
Nominal output level –10 dBV
Maximum output level +6 dBV
EFFECT SEND
1 x 1/4" phone (unbalanced)
Output impedance 1 kΩ
Nominal output level –10 dBV
Maximum output level +6 dBV
PHONES
1/4" stereo jack
Maximum output 30 mW + 30 mW (into 30Ω)
DIGITAL OUT
Optical digital audio output (TOSLINK)
Data format S/PDIF 1
Frequency response 20 Hz — 20 kHz, +1 dB/–3 dB
Signal-to-noise ratio > 85 dB (A-weighting, 22 kHz LPF)
Total harmonic distortion < 0.05% (1 kHz, –10 dBV, 22 kHz LPF, MASTER fader at nominal)

Tascam DP-01 Specifications

General

Tracks	8
Simultaneous Recording Tracks	2
Phantom Power	Yes
Display	LCD
Sampling Frequency	44.1 kHz
A/D Resolution	24-bit
D/A Resolution	24-bit
Power Supply	AC adapter
Inputs	2 x XLR/TRS combo
Outputs	Stereo RCA
EQ	2-band per channel
Effects	Reverb
