Tascam DP-01 User Manual

Specifications
56 TASCAM DP-01 Owner’s Manual
Advanced techniques
Physical characteristics
Dimensional drawing
External power adapter AC input 100 — 240 V AC, 50/60 Hz
External power adapter output 12 V
External power adapter output current 2.5 A
Power consumption 15 W
External dimensions (w x h x d) 452 x 110 x 307 (mm) 17.8" x 4.3" x 12.1"
Weight 4.1 kg (9 lb)
Figure 2.13: Dimensions of the DP-01
452 mm (17.8")
110 mm
(4.3")
307 mm (12.1")

Tascam DP-01 Specifications

General

Tracks	8
Simultaneous Recording Tracks	2
Phantom Power	Yes
Display	LCD
Sampling Frequency	44.1 kHz
A/D Resolution	24-bit
D/A Resolution	24-bit
Power Supply	AC adapter
Inputs	2 x XLR/TRS combo
Outputs	Stereo RCA
EQ	2-band per channel
Effects	Reverb
