Fig. 6B.7 Rear Axle (2- to 3.5-ton Trucks)
KNUCKLE (RIGHT)
TIE ROD (RIGHT)
TIE ROD (LEFT)
KNUCKLE (LEFT)
CENTER ARM
KING PIN
POTENTIOMETER
View looking from
B
Detail of
A
Point notched surface
toward knuckle’s shaft
SUPPORT (FRONT)
SUPPORT (REAR)
