TCM FB30-8 - Page 158

- 132 -
A A
①
②
⑤
④
③
⑥
断面 -
A A
1. LENS
2. RIM
3. HOUSING
4. REFLECTOR
5. GASKET
6. BULB
Fig. 9.7 Head Lights
(3) Head lights
The head lights are installed on the upper part of the front legs of the overhead guard.
Sectional view
A
-
A
9. ELECTRIC SYSTEM
