05. LUBRICATION
1. Lubricating lift chains
Lubricate the lift chains with engine oil using an oiler or a brush.
To allow oil to enter between each pin and link plate of the lift chain, observe the following
conditions:
Loosen the chains sufciently.
•
After applying engine oil, operate the lift cylinders at least ten times through full travel.
•
NOTE
If your lift truck is used near a port or coastal area, the lift chains might be damaged from salty
breezes. After a storm or typhoon, it is advisable to wash them with water before lubricating in the
above manner.
2. Mast and steering system
Fig. 05.1
Fig. 05.2
■ Rear slippers of the mast
WARNING
Do not ride on the mast. Do not put your hand or
foot on the connecting member across the mast
or between the outer and inner mast channels;
otherwise you might get injured if the mast
accidentally moves.
To Next Page
