- 7 -
(2) Diode
The diode, installed inside the right-side frame, is a 3-phase, full-wave rectication type which
converts AC to DC.
The current rectied by the diode ows through the fuse F6 to charge the battery.
ヒューズ : 130A
トランスへ
ダイオード
Fig. 1.7 Diode
DIODE
to TRANSFORMER
FUSE: 130 A
1. BATTERY AND CHARGER (OPTION)
