12 CONF Button / Indicator Activates the Configuration menu.
The Configuration menu provides power supply start mode
control, Voltage & Current source control, Analog
Programming / Monitoring range selection, Internal
Resistance function, Constant power limit function, and Slew-
Rate control function.
Green LED lights when the Configuration menu is active.
If the Configuration menu is active, press the CONF button to
exit to the main menu. *
13 PROT Button / Indicator Activates the Protection menu.
The Protection menu provides OVP setting, UVL setting, UVP
function control, Foldback function control, and OCL function
ON/OFF control.
Green LED lights when the Protection menu is active.
If the Protection menu is active, press the PROT button to
exit to the main menu. *
14 COMM Button / Indicator Activates the Communication menu.
The Communication menu provides communication interface
selection, power supply address selection, LAN settings
control, communication baud-rate selection, communication
language selection, and software revision information.
Green LED lights when the Communication menu is active.
If the Communication menu is active, press the COMM button
to exit to the main menu. *
15 FINE Button / Indicator Voltage/Current Fine/Coarse adjustment control.
Operates as a toggle switch.
In the Fine mode, Voltage and Current encoders operate in
high-resolution mode.
In the Coarse mode, Voltage and Current encoders operate in
standard-resolution (approx. 3 turns for full voltage/current
rated scale).
Green LED lights when the unit is in the Fine mode.
