20
Display Text
Text Description
Display Text
Text Description
PANEL
PANEL
TRIG
TRIGGER
E.VOL
EXTERNAL VOLTAGE
INIT
INIT
E.RES
EXTERNAL RESISTANCE
ABORT
ABORT
C.SRC
CURRENT SOURCE
LOAD
LOAD
RANGE
RANGE
TRG.IN
TRIGGER INPUT
R.INT
INTERNAL RESISTANCE
EXT
EXTERNAL
C.PWR
CONSTANT POWER
BUS
BUS
POWER
POWER
CONT
CONTINUES
SLEW
SLEW
TRG.DL
TRIGGER DELAY
CSL.UP
CURRENT SLEW UP
TRG.OU
TRIGGER OUT
CSL.DN
CURRENT SLEW DOWN
FSTR
FUNCTION STROBE
VSL.UP
VOLTAGE SLEW UP
OPT
OPTIONAL COMMUNICATION
VSL.DN
VOLTAGE SLEW DOWN
RES
RESISTANCE
Table 2-5: Front Panel Display Messages
2.7 Menu Navigation
2.7.1 Introduction
Power Supply series contains the following five independent menus:
• COMMUNICATION
• PROTECTION
• CONFIGURATION
• SYSTEM
• PROGRAM
1. To enter a menu, press COMM, PROT, CONF, SYST or PROG button.
An appropriate LED lights indicating that a menu is active.
2. Navigate the menu by rotating the Voltage encoder to scroll through the selected Menu
functions.
3. Rotate the Current Encoder to select a parameter or a parameter value.
4. Press the Current Encoder to accept a desired parameter value.
5. If the parameter is accepted, the display blinks once indicating the parameter is accepted.
