Serial Communication Test Set-Up
Basic set-up to test serial communication operation.
1 Equipment
PC with a serial communication terminal software installed, Power
Supply and RS232 or USB cable.
2 PC Set-up
Bits per second: 115200
Data bits: 8
Parity: None
Stop bits: 1
Flow control: None
3 Power Supply Set-up
Connect Power Supply to the PC using RS232 or USB cable.
Set Power Supply settings:
Baud Rate – 115200
Address – 06
Interface – RS232 or USB
Communication Language – GEN
4 Communication
PC write: ADR 06
Power Supply response: OK
PC write: OUT 1
Power Supply should turn output ON.
Power Supply response: OK
PC write: PV n (for n values, refer to
Table 5-4)
Power Supply response: OK
PC write: PC m (for m values, refer to
Table 5-5)
Power Supply response: OK
Display indicates the output voltage and actual output current.
If Blank Panel Power Supply is tested, add the following commands to
measure the output voltage and output current settings:
PC write: PV?
Power Supply response: n (actual voltage setting)
PC write: PC?
Power Supply response: m (actual current setting)
NOTE:
If USB communication is used, the USB driver installation is required prior communication.
