TDK-Lambda G30-170 - Status Commands

96
PCS <DSC>
Function Set the Current programming source: Front Panel, External Resistor, or External
Voltage.
Parameters
0|1|2 or DIG|VOL|RES
Query
PCS?
Returns
<DSC> DIG|VOL|RES
APR <DSC>
Function Set the Power Supply analog programming & monitoring range.
Programming – 5/10 volt or 5/10kΩ.
Monitoring – 5/10 volt
Parameters
5|10
Query
APR?
Returns
<DSC> 5|10
REL1 <Bool>
Function
Set the Programmable Pin 1 state (J1.21). 0 – MOSFET ON. 1 – MOSFET OFF.
Parameter
0|1, OFF|ON
Query
REL1?
Return
<Bool> 0|1
REL2 <Bool>
Function
Set the Programmable Pin 2 state (J1.20). 0 – MOSFET ON. 1 – MOSFET OFF.
Parameter
0|1, OFF|ON
Query
REL1?
Return
<Bool> 0|1
5.10.9 Status Commands
Refer to section 7.3.1 for GEN Registers tree.
STT?
Query Reads the complete power supply status.
Returns ASCII characters representing the following data, separated by commas.
MV<actual (measured) voltage>,PV<programmed (set) voltage>,
MC<actual (measured) current>,PC<programmed (set) current>,
SR<status condition register>,FR<fault condition register>
Example
MV(10.000),PV(10.000),MC(04.000),PC(05.000),SR(04ff),FR(00C0)
