Rear Panel features
• Ethernet RJ-45 connector (standard 8-pin phone jack for LAN)
• Link, Activity LED and Speed LED on RJ-45 connector
• LAN Status LEDs show LAN fault and
“Blink Identify” on rear panel, close to LAN RJ-45
connector
RS-485 Multi-drop Chain
• Allows connection of up to 31 power supplies using simple Link cable.
• One LAN IP address shared by all RS-485 power supplies.
Trademark Notices
Microsoft, Internet Explorer and Windows are trademarks of Microsoft Corporation.
5.7.2 Specifications
5.7.2.1 LAN Specifications
ELECTRICAL
Ethernet Meets IEEE 802.3u specifications
Auto-MDIX Accepts patch or cross-over cable connection
Auto-Negotiate Selects fastest of 10Base-T or 100Base-T networks
(10 or 100 Megabits per second)
NETWORK CONFIGURATION
MAC Address TDK-Lambda assigned: 00:19:f9:xx:xx:xx
xx:xx:xx is the unique address for each unit
IP Address View or set from the Front Panel or embedded web page
DHCP Receive an address from network server. Leasing services
Auto-IP Create its own IP address: 169.254.xxx.xxx
Static IP Any IP fixed by an operator
Address
Resolution
ARP Protocol
Hostname DNS and mDNS protocols. Operator settable hostname
Service Name DNS-SD Service Discovery Protocol
Duplicate IP
Detection
Reject duplicate setting or disconnect from network
Subnet Mask Mask set by DHCP or static
Default
Gateway
Address set by DHCP or static
DNS Server Address set by DHCP
LAN Reset Reset configuration
