TECDrive20-EU Series Inverter Communication protocol
-124-
START
T1-T2-T3-T4
ADDR
02H
CMD
06H
High bit of writing data address
00H
Low bit of writing data address
04H
High bit of data content
13H
Low bit of data content
88H
CRC CHK low bit
C5H
CRC CHK high bit
6EH
END
T1-T2-T3-T4
Note: Sections 7.3.1.1 and 7.3.1.2 mainly describe the command formats.
7.3.1.3 Command code 10H, continuous writing
Command code 10H means that if the master writes data to the inverter, the data number
depends on the "data number" in the command code. The max. continuous reading number is
16.
For example, write 5000 (1388H) to 0004H of the inverter whose slave address is 02H and 50
(0032H) to 0005H, the frame structure is as follows:
The RTU request command is:
START
T1-T2-T3-T4 (transmission time of 3.5 bytes)
ADDR
02H
CMD
10H
High bit of write data
00H
Low bit of write data
04H
High bit of data number
00H
Low bit of data number
02H
Byte number
04H
High bit of data 0004H
13H
Low bit of data 0004H
88H
High bit of data 0005H
00H
Low bit of data 0005H
32H
Low bit of CRC
C5H
High bit of CRC
6EH
END
T1-T2-T3-T4 (transmission time of 3.5 bytes)
The RTU response command is:
START
T1-T2-T3-T4 (transmission time of 3.5 bytes)
ADDR
02H
