TECDrive20-EU Series Inverter Dimension drawings
-145-
Installation bracket 1 Customer installation dimensions
Installation bracket 2 Customer installation dimensions
Figure B-3 Outline and installation dimensions
B.2 Inverter chart
Figure B-4 Wall mounting of 0.75–2.2kW inverters (Dimension unit: mm)
