TEC TECDrive20-EU Series - C2 Filter Model Selection

TECDrive20-EU Series Inverter Optional peripheral accessories
-159-
C.6.5 C2 filter model selection
Model
Input filter
Output filter
TDI20-0R4G-S2-EU
FLT-PS2010H-B
FLT-L04006L-B
TDI20-0R7G-S2-EU
TDI20-1R5G-S2-EU
FLT-PS2025L-B
FLT-L04016L-B
TDI20-2R2G-S2-EU
TDI20-0R4G-2-EU
FLT-P04006L-B
FLT-L04006L-B
TDI20-0R7G-2-EU
TDI20-1R5G-2-EU
FLT-P04016L-B
FLT-L04016L-B
TDI20-2R2G-2-EU
TDI20-004G-2-EU
FLT-P04032L-B
FLT-L04032L-B
TDI20-5R5G-2-EU
TDI20-7R5G-2-EU
FLT-P04045L-B
FLT-L04045L-B
TDI20-0R7G-4-EU
FLT-P04006L-B
FLT-L04006L-B
TDI20-1R5G-4-EU
TDI20-2R2G-4-EU
TDI20-004G-4-EU
FLT-P04016L-B
FLT-L04016L-B
TDI20-5R5G-4-EU
TDI20-7R5G-4-EU
FLT-P04032L-B
FLT-L04032L-B
TDI20-011G-4-EU
TDI20-015G-4-EU
FLT-P04045L-B
FLT-L04045L-B
TDI20-018G-4-EU
TDI20-022G-4-EU
FLT-P04065L-B
FLT-L04065L-B
TDI20-030G-4-EU
TDI20-037G-4-EU
FLT-P04100L-B
FLT-L04100L-B
TDI20-045G-4-EU
TDI20-055G-4-EU
FLT-P04150L-B
FLT-L04150L-B
TDI20-075G-4-EU
TDI20-090G-4-EU
FLT-P04240L-B
FLT-L04240L-B
TDI20-110G-4-EU
Note:
 The input EMI meets the C2 requirements after an input filter is configured.
 The preceding table describes external accessories. You need to specify the ones you
choose when purchasing accessories.
