TECDrive20-EU Series Inverter Communication protocol
-131-
Function
Address
Data description
R/W
characteristics
Bi1–2: =00: motor 1 =01: motor 2
=10: motor 3 =11: motor 4
Bit3: =0: asynchronous motor =1:
synchronous motor
Bit4: =0: pre-alarm without overload
=1:overload pre-alarm
Bit5– Bit6 :=00: keypad control
=01: terminal control
=10: communication control
Inverter fault code
2102H
See the fault type instruction
R
Identifying code of
the inverter
2103H
TDI20-EU-----0x0106
R
Operation frequency
3000H
0–Fmax, unit: 0.01Hz
Compatible
with the
communication
addresses of
TDI series.
R
Setting frequency
3001H
0–Fmax, unit: 0.01Hz
R
Bus voltage
3002H
0.0–2000.0V, unit:
0.1V
R
Output voltage
3003H
0–1200V, unit: 1V
R
Output current
3004H
0.0–3000.0A, unit:
0.1A
R
Operation speed
3005H
0–65535, unit: 1RPM
R
Output power
3006H
-300.0–300.0%, unit:
0.1%
R
Output torque
3007H
-250.0–250.0%, unit:
0.1%
R
PID setting
3008H
-100.0–100.0%, unit:
0.1%
R
PID feedback
3009H
-100.0–100.0%, unit:
0.1%
R
Input state
300AH
000–1FF
R
Input state
300BH
000–1FF
R
AI 1
300CH
0.00–10.00V, unit:
0.01V
R
AI 2
300DH
0.00–10.00V, unit:
0.01V
R
AI 3
300EH
-10.00–10.00V, unit:
0.01V
R
AI 4
300FH
Reserved
R
