TECDrive20-EU Series Inverter Communication protocol
-137-
If the operation is successful, the response may be as below (the same with the command
sent by the master):
Parameter
address
CRC
Inverter
address
Write
command
Forward
running
ASCII mode:
The command sent to the inverter:
Parameter
address
Inverter
address
Write
command
LRC
Data
number
If the operation succeeds, the response message is as follows:
Parameter
address
Inverter
address
Write
command
LRC
check
Data
number
Example 2: set the max. output frequency of the inverter with the address of 03H as100Hz.
Function
code
Name
Description
Default
Modify
P00.03
Max. output
frequency
Used to set the max. output frequency of
the inverter. It is the basis of frequency
setup and the acceleration/deceleration.
Setting range: P00.04–400.00Hz
50.00Hz
◎
See the figures behind the radix point, the fieldbus ratio value of the max. output frequency
(P00.03) is 100. 100Hz timed by 100 is 10000 and the corresponding hex is 2710H.
RTU mode:
The command sent by the master:
Parameter
address
Inverter
address
Write
command
CRC
Parameter
data
If the operation is successful, the response may be as below (the same with the command
sent by the master):
Parameter
address
Inverter
address
Write
command
CRC
Parameter
data
