TECDrive20-EU Series Inverter Optional peripheral accessories
-162-
 The materials near the braking resistor must be non-flammable. The
surface temperature of the resistor is high. Air flowing from the resistor is of
hundreds of degrees Celsius. Prevent any materials from contacting the
resistor.
Inverters need only external braking resistors.
PB
External
brake
resistor
Inverter
(+)
