TECDrive20-EU Series Inverter Installation guidelines
-21-
Type
Terminal
name
Function
description
Technical specifications
4. Max. input frequency: 1kHz
HDI
High frequency
input channel
Except for S1–S4, this terminal can be
used as high frequency input channel.
Max. input frequency: 50kHz
Duty cycle: 30%–70%
PW
Digital power supply
The working power of digital input is
provided by an external power supply.
Power range: 12 V–30 V
Y1
Digital output
1. Contact capacity: 50mA/30V;
2. Output frequency range: 0–1kHz;
3. Default is STO state output indicator.
STO function
input
24V-H1
STO input 1
1. Safe torque off (STO) redundant inputs,
connected to external NC contacts. When
the contacts open, STO acts and inverter
output stops.
2. Safety input signal cable: shielded, with
length within 25m
3. H1 and H2 terminals are short connected
to +24V by default. Remove the jumper on
the terminal before using STO function.
24V-H2
STO input 2
24V power
supply
+24V
24V power supply
External 24V±10% power supply and the
maximum output current is 200mA.
Generally used as the operation power
supply of digital input and output or external
sensor power supply
COM
Analog
input/output
+10V
External 10V
reference power
supply
10V reference power supply
Max. output current: 50mA
As the adjusting power supply of the
external potentiometer
Potentiometer resistance: 5kΩ above
AI2
Analog input
1. Input range: AI2 voltage and current can
be chosen: 0–10V/0–20mA; AI3:
-10V–+10V.
2. Input impedance: voltage input: 20kΩ;
current input: 500Ω.
AI3
