The inverter runs at the lower limit frequency if the
set frequency is lower than the lower limit.
Note: Max. output frequency ≥ upper limit
frequency ≥ lower limit frequency
Setting range: 0.00Hz–P00.04 (upper limit of the
running frequency)
Note: A frequency and B frequency cannot set as
the same frequency reference method. The
frequency source can be set by P00.09.
0: Set via keypad digits
Modify the value of function code P00.10 (set the
frequency by keypad) to change the frequency by
the keypad.
1: Set via AI1 (corresponding keypad
potentiometer)
2: Set via AI2 (corresponding terminal AI2)
3: Set via AI3 (corresponding terminal AI3)
Set the frequency by analog input terminals. The
inverters provide 3 channels analog input
terminals as the standard configuration, of which
AI1 is adjusting through analog potentiometer,
while AI2 is the voltage/current option
(0–10V/0–20mA) which can be shifted by
jumpers; while AI3 is voltage input (-10V–+10V).
Note: When analog AI2 select 0–20mA input, the
corresponding voltage of 20mA is 10V.
100.0% of the analog input setting corresponds to
the maximum frequency (function code P00.03) in
forward direction and -100.0% corresponds to the
maximum frequency in reverse direction (function
code P00.03)
4: Set via high-speed pulse HDI
The frequency is set by high-speed pulse
terminals. The inverters provide 1 high speed
pulse input as the standard configuration. The
pulse frequency range is 0.00–50.00kHz.
100.0% of the high speed pulse input setting
corresponds to the maximum frequency in
forward direction (function code P00.03) and
-100.0% corresponds to the maximum frequency
