TECDrive20-EU Series Inverter Function parameters
-37-
Function
code
Name
Description
Default
Modify
P00.09
Combination
of the setting
source
0: A, the current frequency setting is A frequency
command
1: B, the current frequency setting is B frequency
command
2: A+B, the current frequency setting is A
frequency command + B frequency command
3: A-B, the current frequency setting is A
frequency command - B frequency command
4: Max. (A, B): The bigger one between A
frequency command and B frequency is the set
frequency.
5: Min. (A, B): The lower one between A
frequency command and B frequency is the set
frequency.
Note: The combination manner can be shifted by
P05 (terminal function)
0
○
P00.10
Keypad set
frequency
When A and B frequency commands are selected
as "keypad setting", this parameter will be the
initial value of inverter reference frequency
Setting range: 0.00 Hz –P00.03 (the max.
frequency)
50.00
Hz
○
P00.11
Acceleration
time 1
Acceleration time means the time needed for the
inverter to speed up from 0Hz to the maximum
output frequency (P00.03).
Deceleration time means the time needed if the
inverter speeds down from the maximum output
frequency (P00.03) to 0Hz.
TDI20-EU series inverters have four groups of
ACC/DEC time which can be selected by P05.
The default ACC/DEC time of the inverter is the
first group.
Setting range of P00.11 and P00.12: 0.0–3600.0s
Depend
on
model
○
P00.12
Deceleration
time 1
Depend
on
model
○
P00.13
Running
direction
selection
0: Runs at the default direction, the inverter runs
in the forward direction. FWD/REV indicator is off.
1: Runs at the opposite direction, the inverter runs
in the reverse direction. FWD/REV indicator is on.
Modify the function code to shift the rotation
direction of the motor. This effect equals to the
shifting the rotation direction by adjusting either
0
○
