6. LSServer, Scanner Shell and Download
2004-11 Operating Manual for the LS Series Scanner No. 30001798 Rev. No. 1.5 6-67
Locating Files
Scanner Shell Files
By default, the files associated with Scanner Shell are stored as subdirectories in
the directory where LSServer.dll is found:
C:\Program Files\Common Files\Tecan\Reader\….
The subdirectories are displayed in the table below:
ype of File File
Extension
Directory
Measurement
parameter
.lsp Parameter
Slide adapter format
.saf SAF
Gain calibration
.dat
.csv
CalData
Crosstalk
.dat CalData
Temporary Files
Temporary files needed for diagnostic and controlling purposes are stored in the
directory:
C :\Documents and Settings\”user name”\Local Settings\
The file types are displayed below:
ype of File File Extension Directory
Focus
.tif Temp
Log
.log
.log1 to .logn
Temp
Note
To see the user name of the person logged on,
press Ctrl + Alt + Delete and the user name will be shown
in the Logon dialog box.
File Management
The default paths for saving files can be changed in the Slide Settings dialog box
on the Folder Options tab. See Folder Options.
