9. Interfaces
2004-10 Technical Manual for sunrise RC, TW, TS, TC, BC, 6F No. T 137 302 Rev No. 1.1 9-3
Description of the serial Interface:
The instrument is controlled by the computer and the communication between
the computer and the instrument is done through a RS-232-C interface.
These interface specifications maybe either to the CCITT interface standard or
to the EIA RS-232-C interface standard.
Implemented RS-232-C Interface Lines :
Shortform Signal Name Description Direction
TxD Transmit Data Reader sends Data on this line Output
RxD Receive Data Reader receives Data on this
line
Input
RTS Request to Send Data from Reader available Output
CTS Clear to Send Computer ready to receive Input
Available Setups:
(default is BOLD)
Baudrate:
300, 600, 1200, 2400, 4800,
9600, 19200, 31250, 38400
Data Bits:
7 or
8
Parity:
No, Even, Odd
Stop Bits:
1 or 2
Protocol:
No, Hardware (RTS, CTS), Software (XON/XOFF)
