6. Optical System
6-2 Technical Manual for sunrise RC, TW, TS, TC, BC, 6F No. T 137 302 Rev No. 1.1 2004-10
6.3 Optical System Diagram
The illustration below illustrates the optical system functions.
SUNRISE ST (Option Standard Optic) Instrument
Transport box
Fiber Optic Unit
Filter Carriage
Lamp
Mirror
Heat
A
bsorbing
Filter
Optical Lens
Reference
Diode
Channel
Microplate
Main Board
SUNRISE TW (Tuneable Wavelength Optic) Instrument
Photo Diode Block
Diode Lens Block
Fiber Optic Unit
Filter Slide Block
Lamp
Mirro
r
Heat Absorbing
Filter
Optical Lens
Re
f
erence
Diode
Channel
Microplate
A/D Converter Board
Blocking
Filter wheel
