2. General
2004-10 Technical Manual for sunrise RC, TW, TS, TC, BC, 6F No. T 137 302 Rev No. 1.1 2-15
2.5 Filter Carriage Description
The sunrise instrument can use the following types of filter carriages:
sunrise Standard, 6 Filter and Gradient Filter (with tuneable wavelength option).
2.5.1 Standard Filter Carriage
The sunrise standard filter carriage has up to four narrow band interference
filters that have a fixed wavelength.
SUNRISE Standard Filter Carriage
When a wavelength is selected, the entered wavelength is compared against the
list of entered filter values for this filter carriage.
If the required filter is fitted in the filter carriage, the filter carriage is moved so that
the required filter is in the light beam.
Note
For more information about the definition of the new and customized filter
slides, see 4.3.4 Define Filter
Filter positions
4 3 2 1
