tecan sunrise RC - Power Board (Standard)

8. Electronic System
2004-10 Technical Manual for sunrise RC, TW, TS, TC, BC, 6F No. T 137 302 Rev No. 1.1 8-7
8.6 Power Board (Standard)
This board is used to control the transport motor, filter carriage motor, the 5 Volt
voltage regulation, the lamp control and for the temperature control of the
instrument (fan).
Front side:
Rear side:
Connector to
CPU board
Connector to
Lamp
Connector to
Power on LED
Connector to
filter transport
Connector to
transport motor
Connector to
power supply
Connector
to fan
