2. General
2004-10 Technical Manual for sunrise RC, TW, TS, TC, BC, 6F No. T 137 302 Rev No. 1.1 2-11
2.3.8 Microplates
Only 96-well format microplates (v-shaped, flat and round including strip-wells)
with transparent bottom can be used with the
sunrise Absorbance Reader.
PARAMETERS CHARACTERISTICS
Max. overall plate height
14.35 mm +/- 0.76 mm
(0.5650 inches +/- 0.0299 inches)
Diameter of wells 7.0 mm (0.276 inches)
Pitch size (center to center) 9.0 mm (0.3543 inches)
Bottom shape V-shaped, Flat and Round bottom
The barcode sticker has to be positioned on the right hand side of the plate,
7 mm from the front-right edge. The barcode may be up to 48 mm long.
7
6
55
A
1
The
sunrise barcode reader supports the following barcode types:
• CODE 39
• Interleaved 2 of 5
• UPC A, UPC E0, UPC E1
• EAN8, EAN 13
• Codabar
• CODE 128
