8. Electronic System
2004-10 Technical Manual for sunrise RC, TW, TS, TC, BC, 6F No. T 137 302 Rev No. 1.1 8-17
Home Position senso
r
of the filter wheel
Circuit Diagram:
GND
OUT
A
K
GND
