12 Technical data
DBS tuner:
Input frequency range 2 x 950 .... 2150 MHz
Input level range - 65 dBm ... - 25 dBm
DBS tuner input 2 x F socket
Input impedance 75 Ohms
Loop Through internal loop through
AFC capture range +/- 3 MHz
Demodulation Shaped QPSK
Symbol rate 2 ... 45 Mbaud/s, SCPC/ MCPC
FEC Viterbi and Reed-Solomon
Viterbi rates 1/2, 2/3, 3/4, 5/6, 7/8, automatic
adjustment
Roll-off Factor 35 %
Demultiplexing: in accordance with ISO 13818-1
Common Interface:
Type 2 Common Interface slots for CI
modules
Power consumption max. 0,3A/5V
Video decoding:
Video compression MPEG-2 and MPEG-1 compatible
Up to MP@ML (main profile @
main level)
Video standard PAL / 25 Hz
Active Picture area 720 pixels x 576 lines
Picture format 4:3 / 16:9
Picture material 16:9 Automatic adjustment for 16:9 TV
sets (via SCART)
Letterbox filtering for 4:3 TV sets
Audio decoding:
Audio compression MPEG-1 & MPEG-2 Layer I and II,
MP3
Audio mode Dual (main/sub), Stereo
Sampling frequencies 32 kHz, 44.1 kHz, 48 kHz
Audio parameters:
Output analogue:
Output level L/R 0,5 V r.m.s. (nominal)
Output impedance 600 Ohms
THD > 60 dB (1 kHz)
S/N > 60 dB
Cross-talk < - 65 dB
Input analogue:
Input level L/R 0,5 V r.m.s. (nominal)
Input impedance > 40 kOhms
Volume when switching on Automatically goes to volume pre-
viously set
102
