4.1 Mains power connection
The digital receiver should only be connected to the mains
pwoer supply when all the cable connections with other com-
ponents of the system have been made. This helps to avoid
damage to the digital receiver as well as to other compo-
nents.
a When you have made all the other connections, use
the mains cable supplied to connect the receiver to a
mains power outlet 230 V/50-60 Hz.
4.2 External unit
4.2.1 Operation with 2 antenna signals
To utilise the full range of functions of your digital receiver,
you should preferably operate it with two separate antenna
signals.
b, c Use suitable co-axial cables to connect the LNB
inputs 1 and 2 of the digital receiver with your
external unit.
Please also note Point 6.4 (antenna settings).
4.2.2 Operation with 1 antenna signal
In exceptional cases you can also operate your receiver with
only a single antenna signal. In this case, however, both the
recording function and the PIP function will only be available
in restricted form.
b Use a suitable co-axial cable to connect the LNB
input 1 of the digital receiver with your external unit.
4.2.3 Operation with a rotating antenna
b When using a rotating antenna, connect the DiSEqC
motor (Level 1.2) with the LNB input 1.
4.3 Connection to a television set
When you have connected your digital receiver with your
television set, it may be necessary to adjust the signal type or
the mode of the Scart socket to your television set.
13
