TechniSat DigiCorder S2 User Manual

4
LNB input
1
LNB input
2
SCART socket
TV
USB socket
Audio outputs
digital
SCART socket
VCR
Audio outputs
analogue
RS 232
interface
Mains
power sok-
ket
Inserting the CI modules:
> Follow the instructions provided by the manufacturers of
the CI module and card.
> Insert the desired Smartcard into the appropriate CI
module.
> Now carefully insert the complete CI module into the slot
provided.
S-Video
output
Programme select
up/down
CI module
slot 2
Eject buttons for
CI modules
On/Standby
Alpha-numeric
display
CI module
slot 1
