TechniSat DIGITRADIO 10 IR User Manual

105
DE
EN
NL
FR
6.4 General device functions
6.4.1 Switching on the device
> First prepare the DIGITRADIO 10 IR for operation as described in Sections6.3.1
and 6.3.4.
> Press the On/Standby buon (18) on the remote control to turn on the
DIGITRADIO 10 IR.
Aer switching on the device for the first time, you must first configure the
first installation wizard. There are details of this in Section 8.
6.4.2 Switching o the device
> By briefly pressing the On / Standby buon you can switch the device to
standby mode. [Standby] appears briefly on the display. The date and time
are shown on the display. The display brightness in standby mode can be
adjusted by following the instructions in Section 16.3.

TechniSat DIGITRADIO 10 IR Specifications

General

Radio type	Internet
Tuner type	Digital
FM band range	87.5 - 108 MHz
DAB band range	174 - 240 MHz
Supported radio bands	DAB+, FM
Preset stations quantity	60
Equalizer	Yes
RMS rated power	- W
Built-in speaker(s)	No
Display type	TFT
Display diagonal	2.8 \
Display resolution	240 x 320 pixels
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.1
Coloration	Monochromatic
Thermometer	-
Antenna type	External
Product color	Black, Silver
Internet radio services supported	Spotify
On Screen Display (OSD) languages	DAN, DEU, DUT, ENG, FIN, FRE, ITA, NOR, POL, POR, SWE
Power source	AC/DC
AC input voltage	230 V
DC input voltage	5 V
AC input frequency	50 Hz
Power consumption (standby)	0.72 W
Power consumption (typical)	1.4 W
Clock mode	24h
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	5 - 90 %

Weight and Dimensions

Width	- mm
