TechniSat DIGITRADIO 10 IR User Manual

110
Alternatively, the INFO buon on the remote control can also be used to scroll
through the displays.
6.4.5.2 Slideshow
Some DAB+ broadcasters broadcast additional information such as the album cover
of the current track, adverts or weather information. The window size can be set
using the OK buon or in the menu under [Display seings] > [Picture size].
7 Menu operation
The menu takes you to all functions and seings for the DIGITRADIO 10 IR. Menu
navigation is carried out with the MENU, BACK, / and OK buons. The menu is
divided into submenus and contains dierent menu items or activatable functions,
depending on the mode. To open the menu, simply press the MENU buon briefly. To
switch to submenus, first press the / buons to display a submenu, then press
the OK buon to access the submenu. An asterisk (*) highlights the current selection.
To close the menu: Press the MENU or BACK buon several times (depending
on which submenu you are in) until the current radio channel is displayed
again.

TechniSat DIGITRADIO 10 IR Specifications

General

Radio type	Internet
Tuner type	Digital
FM band range	87.5 - 108 MHz
DAB band range	174 - 240 MHz
Supported radio bands	DAB+, FM
Preset stations quantity	60
Equalizer	Yes
RMS rated power	- W
Built-in speaker(s)	No
Display type	TFT
Display diagonal	2.8 \
Display resolution	240 x 320 pixels
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.1
Coloration	Monochromatic
Thermometer	-
Antenna type	External
Product color	Black, Silver
Internet radio services supported	Spotify
On Screen Display (OSD) languages	DAN, DEU, DUT, ENG, FIN, FRE, ITA, NOR, POL, POR, SWE
Power source	AC/DC
AC input voltage	230 V
DC input voltage	5 V
AC input frequency	50 Hz
Power consumption (standby)	0.72 W
Power consumption (typical)	1.4 W
Clock mode	24h
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	5 - 90 %

Weight and Dimensions

Width	- mm
