TechniSat DIGITRADIO 10 IR User Manual

119
DE
EN
NL
FR
Stations with a signal intensity below the required minimum signal intensity
are not transmiing a strong enough signal. Align the dipole antenna, if
required, as described in Section 6.3.1.
9.2.7 Manual seing
This menu item is used to check the reception channels and can be used to align the
antenna. Furthermore, stations can be added manually.
> Press the MENU buon and use the / buons to select the [Scan
seings] > [Set manually] entry, then press the OK buon.
> Use the / and OK buons to select a channel (5A to 13F). The signal
intensity will now be shown on the display. If a DAB+ station is being received
on a channel, the station ensemble name is displayed. The antenna can now
be aligned to the maximum signal intensity.
Stations with a signal intensity below the required minimum signal intensity
are not transmiing a strong enough signal. Align the dipole antenna, if
required, as described in Section 6.3.1.

TechniSat DIGITRADIO 10 IR Specifications

General

Radio type	Internet
Tuner type	Digital
FM band range	87.5 - 108 MHz
DAB band range	174 - 240 MHz
Supported radio bands	DAB+, FM
Preset stations quantity	60
Equalizer	Yes
RMS rated power	- W
Built-in speaker(s)	No
Display type	TFT
Display diagonal	2.8 \
Display resolution	240 x 320 pixels
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.1
Coloration	Monochromatic
Thermometer	-
Antenna type	External
Product color	Black, Silver
Internet radio services supported	Spotify
On Screen Display (OSD) languages	DAN, DEU, DUT, ENG, FIN, FRE, ITA, NOR, POL, POR, SWE
Power source	AC/DC
AC input voltage	230 V
DC input voltage	5 V
AC input frequency	50 Hz
Power consumption (standby)	0.72 W
Power consumption (typical)	1.4 W
Clock mode	24h
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	5 - 90 %

Weight and Dimensions

Width	- mm
