TechniSat DIGITRADIO 10 IR User Manual

143
DE
EN
NL
FR
16.1.2 Display seings
> Select [Network info] to display the current network seings.
16.1.3 TechniSat Connect PIN
You can control the DIGITRADIO 10 IR via the TechniSat CONNECT App. To do so, the
PIN for the DIGITRADIO 10 IR must be entered in the App. You can change the PIN as
follows.
> Under [TechniSat CONNECT PIN], enter the 4-digit PIN and press the OK
buon to save it.
16.1.4 Delete network profile
Use the [Delete Inactive Networks ] or [Delete All Networks] menu items to delete
an existing connection to a particular wireless network or to all configured networks
and clear the seings you have made. If you wish to connect the device to this
network again, you must carry out all the seings again.

TechniSat DIGITRADIO 10 IR Specifications

General

Radio type	Internet
Tuner type	Digital
FM band range	87.5 - 108 MHz
DAB band range	174 - 240 MHz
Supported radio bands	DAB+, FM
Preset stations quantity	60
Equalizer	Yes
RMS rated power	- W
Built-in speaker(s)	No
Display type	TFT
Display diagonal	2.8 \
Display resolution	240 x 320 pixels
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.1
Coloration	Monochromatic
Thermometer	-
Antenna type	External
Product color	Black, Silver
Internet radio services supported	Spotify
On Screen Display (OSD) languages	DAN, DEU, DUT, ENG, FIN, FRE, ITA, NOR, POL, POR, SWE
Power source	AC/DC
AC input voltage	230 V
DC input voltage	5 V
AC input frequency	50 Hz
Power consumption (standby)	0.72 W
Power consumption (typical)	1.4 W
Clock mode	24h
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	5 - 90 %

Weight and Dimensions

Width	- mm
