TechniSat DIGITRADIO 10 IR User Manual

142
> Now select whether to allow automatic retrieval of the IP address, gateway
etc. from your router (DHCP active) or if you would like to enter this manually
(DHCP inactive).
Please take into account that automatic retrieval of the IP address, gateway,
subnet mask only works if the DHCP function is activated in your router.
> One by one, enter the IP address, subnet mask, gateway address, primary
DNS and secondary DNS if required, using the Arrow buons on the remote
control. Confirm each set value with the OK buon.
> Now enter the name (SSID) of your WLAN network using the virtual keyboard
and confirm with OK.
> Select whether your WLAN network is Unencrypted, encrypted by WEP or by
WPA/WPA2 and confirm the following item.
> Then use the virtual keyboard to enter your WLAN password and confirm with
OK to start the connection process.
In general, the WLAN connection can be used aer a few seconds.

TechniSat DIGITRADIO 10 IR Specifications

General

Radio type	Internet
Tuner type	Digital
FM band range	87.5 - 108 MHz
DAB band range	174 - 240 MHz
Supported radio bands	DAB+, FM
Preset stations quantity	60
Equalizer	Yes
RMS rated power	- W
Built-in speaker(s)	No
Display type	TFT
Display diagonal	2.8 \
Display resolution	240 x 320 pixels
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.1
Coloration	Monochromatic
Thermometer	-
Antenna type	External
Product color	Black, Silver
Internet radio services supported	Spotify
On Screen Display (OSD) languages	DAN, DEU, DUT, ENG, FIN, FRE, ITA, NOR, POL, POR, SWE
Power source	AC/DC
AC input voltage	230 V
DC input voltage	5 V
AC input frequency	50 Hz
Power consumption (standby)	0.72 W
Power consumption (typical)	1.4 W
Clock mode	24h
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	5 - 90 %

Weight and Dimensions

Width	- mm
