The exact alignment of the telescopic antenna is oen important, in particular
on the outskirts of the DAB+ reception area. On the Internet you can quickly
find the location of the nearest transmission tower by visiting www.dabplus.
de.
Start the first scan at a window pointing in the direction of the transmission
mast. If the weather conditions are poor, DAB+ reception may be limited.
Do not touch the telescopic antenna during station playback. This could
reduce the reception and lead to sound dropouts.
6.3.2 Audio connection to stereo equipment, active speaker
> Use the analogue audio output (4) to connect the device to e.g. the AUDIO
IN on a stereo system or an AV amplifier. Use the supplied audio connection
cable to do so (a special cable may be required, depending on the AV
amplifier input).
> If your AV amplifier has an optical digital input, you can connect the
DIGITRADIO 10 IR to the amplifier via the S/PDIF optical digital output (4).

TechniSat DIGITRADIO 10 IR Specifications

General

Radio type	Internet
Tuner type	Digital
FM band range	87.5 - 108 MHz
DAB band range	174 - 240 MHz
Supported radio bands	DAB+, FM
Preset stations quantity	60
Equalizer	Yes
RMS rated power	- W
Built-in speaker(s)	No
Display type	TFT
Display diagonal	2.8 \
Display resolution	240 x 320 pixels
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.1
Coloration	Monochromatic
Thermometer	-
Antenna type	External
Product color	Black, Silver
Internet radio services supported	Spotify
On Screen Display (OSD) languages	DAN, DEU, DUT, ENG, FIN, FRE, ITA, NOR, POL, POR, SWE
Power source	AC/DC
AC input voltage	230 V
DC input voltage	5 V
AC input frequency	50 Hz
Power consumption (standby)	0.72 W
Power consumption (typical)	1.4 W
Clock mode	24h
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	5 - 90 %

Weight and Dimensions

Width	- mm
