TechniSat DIGITRADIO 10 IR User Manual

114
> Aer completing the network set-up, confirm the message that the initial set-
up has been completed by pressing the OK buon.
9 DAB+ (digital radio) function
9.1 What are DAB+ and DAB+ Cable?
DAB+ is a new digital format through which crystal clear sound with no noise can
be heard. In contrast to conventional analogue radio stations, DAB+ can be used to
broadcast multiple stations on one and the same frequency. This is referred to as an
ensemble or multiplex.
An ensemble is comprised of the radio station, as well as several service components
or data services which are broadcast individually by the radio stations. For further
information, please visit e.g. www.dabplus.de or www.dabplus.ch.
9.2 DAB+ (digital radio) reception
> Press the MODE buon until [DAB] is shown on the display.
If DAB+ is being started for the first time, a complete scan will be performed.
Aer the scan is complete, the first station is played back in alphanumeric
order.

TechniSat DIGITRADIO 10 IR Specifications

General

Radio type	Internet
Tuner type	Digital
FM band range	87.5 - 108 MHz
DAB band range	174 - 240 MHz
Supported radio bands	DAB+, FM
Preset stations quantity	60
Equalizer	Yes
RMS rated power	- W
Built-in speaker(s)	No
Display type	TFT
Display diagonal	2.8 \
Display resolution	240 x 320 pixels
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.1
Coloration	Monochromatic
Thermometer	-
Antenna type	External
Product color	Black, Silver
Internet radio services supported	Spotify
On Screen Display (OSD) languages	DAN, DEU, DUT, ENG, FIN, FRE, ITA, NOR, POL, POR, SWE
Power source	AC/DC
AC input voltage	230 V
DC input voltage	5 V
AC input frequency	50 Hz
Power consumption (standby)	0.72 W
Power consumption (typical)	1.4 W
Clock mode	24h
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	5 - 90 %

Weight and Dimensions

Width	- mm
